Vigilant ISO 8201 Strobe Driver Board PCB Assy 1922-77 (PA1043)
$308.10
ISO 8201 Strobe Driver Board PCB Assy 1922-77
SKU
PA1043
The ISO 8201 Strobe Driver generates an ISO 8201
compliant “T3†pattern for the Multi-Candela strobe
4906-9104.
It connects directly to a supervised relay output of
a fire alarm panel and drives one or more lines of
strobes with a synchronised T3 pattern.
The fire alarm panel’s output supervision supervises
the wiring from the panel to the strobes. The output
signals of up to 5 modules can be synchronised.
Four standoffs are supplied for mounting.
