kidde 40lb cylinder full tank with dimensions 06-100040-000

Kidde Blank 40Lb (18Kg, 16.2 Ltr) Fire Suppression Cylinder, with either Novec-1230 or FM-200 agent (06-100040-000)

Kidde 900lb cylinder three inch rolled groove full tank 480x640 06-100900-000

Kidde Blank 900Lb (408Kg, 368 Ltr) Fire Suppression Cylinder, with either Novec-1230 or FM-200 agent (06-100900-000)

Kidde Blank 70Lb (31Kg, 28.3 Ltr) Fire Suppression Cylinder, with either Novec-1230 or FM-200 agent (06-100070-000)

Kidde Blank 70Lb (31Kg, 28.3Ltr) Cylinders, which can be filled with between 15.9Kg and 31.8Kg of Gas Suppression Agent. (06-100070-000 )
SKU
06-100070-000

FSP Can Supply new, Refill, Hydrostatic test and service Kidde Blank 70Lb (31Kg, 28.3Ltr) Cylinders, which can be filled with between 15.9Kg and 31.8Kg of Gas Suppression Agent. (06-100070-000 ) The cylinders are equipped with a 1.5-inch pressure differential valve and pressure gauge. The safety burst disc is also located on the cylinder head.

Contact us if you need these cylinders with the optional liquid level indicator or optional low-pressure switch assembly.

Novec-1230 is required to be kept under pressure otherwise it vaporises. Dry Nitrogen is used to provide the constant pressure required to keep the agent in liquid form in the tank.

Kidde Blank 70Lb (31Kg) Cylinder Specifications

  • Height = 890mm
  • Valve Size = 1.5inch
  • Min Fill = 15.9Kg
  • Max Fill = 31.8Kg
  • Gross Weight = 59.9Kg
kidde cylinder size
